Multi Levels Independent Type Automated Parking Garage System

Basic Info

Model NO.	ARP-10S
The Vehicle Inlet and Outlet	Down
Design	Four Post
Certification	CE, ISO, TUV
Lift Mode	Chain
Voltage	380V, 50Hz, 3p
Transport Package	Factory Standard
Specification	Q235 Steel
Trademark	Jiuroad
Origin	China
HS Code	84289020
Production Capacity	1000 Units/Month

Product Description

Model Number	ARP-10S
Parking spaces	10 SUVs
Motor power (kw)	9.2
System height (mm)	14,400
Max retrieve time (s)	150
Rated capacity (kg)	2500
Car size (mm)	SUV Allowed; L*W*H=5300*2100*2000
Cover area (mm)	L*W=6,500*5,700
Power supply	380v, 50hz, 3ph (standard)
Operation	Button / ID Card
Finishing	Powder coating
